Usage of single tank ultrasonic cleaner

1. Put the articles to be cleaned into the cleaning basket of the single tank ultrasonic cleaner, and then put the cleaning basket into the cleaning bath. Do not put the articles directly into the cleaning bath to avoid damaging the equipment and cleaning effect.

2. According to different products or cleaning effects, pour cleaning solution, water or aqueous solution in proportion. The water level shall not be lower than 60mm and the height shall not exceed 80mm.

3. Connect the 220V/50Hz power three core socket and connect the power.

4. Turn on the switch button of the single tank ultrasonic cleaner, and the green switch will light up to show that it works normally.

5. Turn on the temperature control of the ultrasonic cleaner to adjust the temperature according to the cleaning requirements.

6. The temperature indicator turns off and the heater meets the required requirements. The heater will stop working. If it is lower than the set temperature, the heater will continue to heat automatically.

7. When the heating temperature reaches the product cleaning requirements, the cleaning timer can be started, and the working time of the timer can be set according to the product cleaning requirements.

8. The cleaning time for general articles is 10 to 20 minutes. For the workpieces that are difficult to clean, the cleaning time can be appropriately extended to ensure the cleaning effect.

9. The timer position can be adjusted arbitrarily within 1-20min, or it can be adjusted to the normal position. Generally, the cleaning time is 10~20min. For parts that are difficult to clean, the cleaning time can be appropriately extended.

10. After cleaning, take out the cleaning basket from the cleaning tank and wash it with warm water or rinse it in another warm water cleaning tank without solvent.

11.The articles shall be dried, stored and assembled after cleaning.
