Dual Motor Ultrasonic Lace Machine
X30 is a manual high-power ultrasonic lace machine. The core components composed of an intelligent frequency tracking ultrasonic generator, a high-Q transducer, and a wear-resistant tool head have good performance when used in cutting, welding, and stitching. Dual-motor drive system, adjustable speed, automatic frequency tracking ultrasonic generator drive, manual pressure adjustment, multiple selection of flower wheels and abnormal alarm function.....
The dual motor ultrasonic lace machine applies ultrasonic technology to apparel processing. It uses the interaction between ultrasonic wave and flower wheel to generate mechanical energy and heat energy to cut and sew the lace of various chemical fibers and blended fabrics. In order to further improve the technical performance and application range of ultrasonic lace machine, increasing function and reducing cost become more important. The dual motor ultrasonic lace machine is suitable for the production of lace curtains, leather embossing, non-woven stitching, clothing cutting, packaging ribbons, flower banners, jewelry cutting, etc.
Parameters
| Model | X30-D54 | X30-L110 | X30-L220 |
| Ultrasonic frequency | 20KHz | 20KHz | 20KHz |
| Ultrasonic power | ≤2600W | ≤2600W | ≤2600W |
| Ultrasonic generator | JYD-2900SP | JYD-2900SP | JYD-2900SP |
| Ultrasonic transducer | JYD-5020-6P8-AU | JYD-5020-6P8-AU | JYD-5020-6P8-AU |
| Ultrasonic booster | S20-D54D38H129-H | S20-D54D38H129-H | S20-D54D38H129-H |
| Motor | Single/asynchronous motor 60W 0.8A 110V 60Hz | Single/asynchronous motor 60W 0.8A 110V 60Hz | Single/asynchronous motor 60W 0.8A 110V 60Hz |
| Reducer | / | / | / |
| Working methods | external | built-in | built-in |
| Boding width | ≤16mm | ≤100mm | ≤210mm |
| Flower wheel diameter | 50mm | 50mm | 50mm |
| Max speed | 20m/min | 20m/min | 20m/min |
| Working space | 370mm*155mm | 370mm*155mm | 370mm*155mm |
| Machine body size | 500mm*125mm*265mm | 500mm*125mm*265mm | 500mm*125mm*265mm |
| Whole machine size | 1210*600mm*1100mm | 1210*600mm*1101mm | 1210*600mm*1101mm |
| Power supply | 220v±10% 50-60Hz | 220v±10% 50-60Hz | 220v±10% 50-60Hz |
| Package methods | Export wooden case | Export wooden case | Export wooden case |
| Package size | 1250mm*600mm*1080mm | 1250mm*600mm*1080mm | 1250mm*600mm*1080mm |
| Weight | 88.5KG | 88.5KG | 88.5KG |
Features
-
Full computer control
-
Intelligent automatic follow-up
-
Powerful and stable
-
Cope with a variety of fabrics
-
Can work continuously
-
Adjustable foot pedal position
-
Comfortable foot pedal
Details
1.The intelligent ultrasonic generator is controlled by microcomputer,which is intelligent
2. The ultrasonic head has stable performance, high efficiency, stable output power and can work continuously for a long time
3. The operation interface is simple and easy to understand
4. Mechanical foot switch, stepless speed change, step deep and shallow
Five advantages:
Factory direct sales: manufacturing and sales are integrated, first-hand supply, quality is guaranteed
Processing customization: physical manufacturers can customize products according to customer requirements, please contact customer service for details of customization
After-sales guarantee: customer service is online all day to ensure timely response
Super durable: the raw materials are carefully selected to ensure the high quality of the products
Excellent team: one-stop service to provide you with the complete machine and accessories, we sincerely look forward to working with you.
FAQ
Q1:What about the mechanical quality?
A:You may rest assured that all of our Dual Motor Ultrasonic Lace Machine have passed the inspection before they leave the factory , and we provide a two-year warranty.
Q2:Can the machine be used directly if you get it?
A:Yes, we are all debugged out of the factory, just need to plug in the power.
Q3:How about the speed of logistics?
A:Domestic we use the way of logistics, we ship ferries abroad, also can choose to air.
Q4:Can the pattern of machine's roller to be customerized?
A:Yes, our engineers only need pictures from you.
Applications
Dual motor ultrasonic lace machine is suitable for chemical fiber fabrics, nylon fabrics, knitted fabrics, non-woven fabrics, spray sponges, PE, PE+ cloth composite materials. The main uses are lace garments, lace underwear, flower packaging ribbons, bedspreads, duvet covers, Accounts, raincoats, umbrellas, tablecloths, curtains, handkerchiefs, luggage, non-woven products, disposable surgical gowns, caps, masks, motorcycle caps, handicrafts/clothes, mouth cloths, chopstick covers, seat covers, coasters , Curtains, raincoats, PVE handbags, umbrellas, food packaging bags, tents, shoes and hats products, disposable surgical gowns, masks, surgical caps, car steering wheel covers, anti-lattice heat sealing, reflective film heat sealing, reflective film heat sealing, car cushions, Seat cushion, foot pad welding, backrest, foot pad embossing, medical eye mask, etc.
For more details of Dual Motor Ultrasonic Lace Machine, please feel free to contact us!
